vacuum shelf tray dryer

vacuum shelf tray dryer

4.50 - 22.00 INR/Unit

Product Details:

  • Type Other
  • Material stainless steel & mield steel
  • Computerized No
  • Control Mode Semi-Automatic
  • Voltage 415
  • Power 50 hz,3 phase
  • Warranty 1
  • Supply Ability : 20 Unit Per Month
  • Click to view more
X

Price And Quantity

  • 1 Unit
  • 4.50 - 22.00 INR/Unit

Product Specifications

  • stainless steel & mield steel
  • Other
  • 1
  • 50 hz,3 phase
  • No
  • 415
  • Semi-Automatic

Trade Information

  • 20 Unit Per Month
  • 1 Months
  • Asia
  • All India

Product Description

The Vacuum Shelf Tray Dryer Is Basically A Tray DryerWorking Under Vacuum Conditions. Its Use Vacuum To Pump Air And Humidity OutFrom The Closed Heat Chamber Due To Vacuum Making The Chamber On The VacuumState Thus Increased Drying Rate Greatly And Saved Energy. The Boiling Point OfThe Material To Be Brought Down For Drying And The Entire System Is In ClosedLoops So ,No Contamination Occurs.The Evaporation's Evolved During The DryingProcess Is Cooled Down Through A Connected Condenser And Collected InReceiver.Vacuum Shelf Dryer Is Closed Chamber With Heavy Structure With AirLock Doors,Jacketed And Insulated Body There Are Shelves For Resting TrayInside Chamber.Shelves Are Manufactured In Hollow Construction With Baffles CumStiffeners, Inlet Header To Each Shelf , So Heat Transfer To The Surface ,Which In Turn Heats Up Trays Placed On The Shelves.The Hot Media Flows Out FromThe Shelves Through The Outlet Header.
